Max Platform Height: 10.5 Meters
Max Working Height: 12.5 Meters
Loading Capacity: 200kg
Platform Size: 800*930mm
Power: Rechargeable Battery
Suitable for 2 Workers Use
Automatic Walking Mode
Certificate: CE,ISO,ROHS,Saber
| Category | Item | Description | Value |
|---|---|---|---|
| Dimensions | 1 | Max. Working Height | 11.2 m |
| 2 | Max. Platform Height | 9.2 m | |
| 3 | Working Outreach | 3 m | |
| 4 | Up and Over Height | 7.89 m | |
| 5 | Overall Length | 2.53 m | |
| 6 | Overall Width | 1 m | |
| 7 | Overall Height (stowed) | 1.99 m | |
| 8 | Platform Dimension (L × W) | 0.62 × 0.87 m | |
| 9 | Ground Clearance (Stowed) | 70 mm | |
| 10 | Ground Clearance (Raised) | 70 mm | |
| 11 | Wheelbase | 1.22 m | |
| 12 | Tyres | Φ381×127 mm | |
| Weight | 1 | Weight | 2950 kg |
| Performance | 1 | Loading Capacity | 200 kg |
| 2 | Occupants (Indoor / Outdoor) | 2 / 1 | |
| 3 | Gradeability | 25% | |
| 4 | Max. Allowance Tilt Angle (X/Y) | X‑2°, Y‑2° | |
| 5 | Swing (Continuous Rotation) | 345° | |
| 6 | Jib‑Range of Articulation | ±60° | |
| 7 | Travel Speed (Stowed) | 4.5 km/h | |
| 8 | Travel Speed (Raised) | 0.5 km/h | |
| Power System | 1 | Battery | 24V / 240Ah |
| 2 | Charger | 24V / 30A | |
| 3 | Driving Motor | 24V / 0.9 kW | |
| 4 | Lifting Motor | 24V / 3 kW |
