Max Platform Height: 3 Meters
Max Working Height: 5 Meters
Loading Capacity: 300kg
Platform Size: 1170*600*1100mm
Power: Rechargeable Battery
Automatic Walking Mode
Certificate: CE,ISO,ROHS,Saber
| Model Type | JCPT0806C | JCPT1008C | JCPT1210C | JCPT1412C |
| Working Height | 8m | 10m | 12m | 14m |
| Max Lifting Height | 6m | 8m | 10m | 12m |
| Load Capacity | 500Kg | 450Kg | 320Kg | 320Kg |
| Load capacity of Extendable Platform | 113Kg | |||
| Overall Dimension of the machine (Guardrail not folded) |
2.78*1.57*2.35m | 2.78*1.57*2.47m | 2.78*1.57*2.64m | 2.78*1.57*2.74m |
| Platform Size | 2.27*1.13m | |||
| Extendable Platform | 900mm | |||
| Min Turning Radius(m) | 0 | |||
| Min Ground Clearance(m) | 0 | |||
| Max. Allowable Working Angle | 1.5-3° | |||
| Max. Climbing Ability | 0.25 | |||
| Lifting Motor | 48V/4.5Kw | |||
| Driving Motor | 48V/4Kw | |||
| Driving Speed | 1.8Km/h | |||
| Lifting up/down Speed | 80/35sec | |||
| Battery | 8x6V/240Ah | 8x6V/200Ah | 8x6V/240Ah | 8x6V/240Ah |
| Charger | 48V/30A | |||
| Machine Weight | 2770Kg | 2970kg | 3270kg | 3680kg |
